File:16 pin DIP socket.jpg
Size of this preview: 799 × 600 pixels.
Original file (799 × 600 pixels, file size: 312 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
A 16-pin machined-pin (turned-pin) DIP socket with round gold-plated receptacles, described by the photographer as a Mill-Max socket. Copied from Wikimedia Commons.
Source
[edit | edit source]
Wikimedia Commons, File:16 pin DIP socket.jpg (retrieved 2026-10-25), originally posted to Flickr by the author on 18 March 2009.
Author
[edit | edit source]
Nick Ames
Licence
[edit | edit source]
CC BY-SA 2.0, as stated on Wikimedia Commons.
