Summary

Commodore Business Machines drawing 320082, sheet 2 of 3, PET Computer Main Logic, Memory Section, for Commodore PET 2001 board assembly 320081. Monochrome scan, 5,096 × 3,296 pixels. Commodore's note on the sheet says that all component locations are the same on boards 320008, 320081, 320132 and 320137, and only the fitted parts differ. Described on Schematic 320082 (Sheet 2 of 3, Board 320081).

Source

http://www.zimmers.net/anonftp/pub/cbm/schematics/computers/pet/2001/320081-2.gif (same file name and size, 283,304 bytes; retrieved 2026-10-01).

Author

Commodore Business Machines, Inc.

Licence

Copyright Commodore Business Machines, Inc. Not freely licensed. Hosted for preservation and repair reference.
