Commodore Business Machines drawing 320130, sheet 2 of 3, PET Computer Main Logic, Memory Section, for Commodore PET 2001 board assembly 320132. Monochrome scan, 5,096 × 3,296 pixels. Commodore's note on the sheet says that all component locations are the same on boards 320008, 320081, 320132 and 320137, and only the fitted parts differ. Described on Schematic 320130 (Sheet 2 of 3, Board 320132).
