File:ANTIC chip on an Atari 130XE motherboard.jpg

Size of this preview: 800 × 366 pixels. Other resolution: 2,484 × 1,137 pixels.

Original file (2,484 × 1,137 pixels, file size: 2.45 MB, MIME type: image/jpeg)

Summary

An ANTIC chip (AMI 8735MBU, C021697-01) soldered on an Atari 130XE main board.

ANTIC chip on an Atari 130XE motherboard.jpg on Wikimedia Commons (retrieved 2026-10-25).

Rod Castler (Wikimedia Commons).
