File:Acorn A5000 motherboard.jpg
Summary
[edit | edit source]
Acorn Archimedes A5000 main board, from above: the memory chips at bottom left with the expansion socket on the board edge, the four RISC OS ROMs with an empty fifth socket, the interface ports along the top edge, the podule backplane connector on the right and the IDE and floppy connectors at bottom right. 405 × 480 pixels.
Source
[edit | edit source]
https://chrisacorns.computinghistory.org.uk/Pics/A5000A6.jpg, on the page Computers/A5000.html of Chris's Acorns (Chris Whytehead's collection, hosted by The Centre for Computing History); identical file (retrieved 2026-10-01).
Author
[edit | edit source]
Chris Whytehead.
Licence
[edit | edit source]
Chris's Acorns states that its text and photographs may be reused under CC BY-SA 3.0 unless otherwise specified, with Chris's Acorns credited as the source (Chris's Acorns home page, retrieved 2026-10-01).
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 21:18, 17 June 2026 | | 405 × 480 (51 KB) | Josh (talk | contribs) | Acorn Archimedes A5000 motherboard (25 MHz, board 0192,100). The four RISC OS 3 ROMs (with an empty fifth socket), the ARM3, MEMC1a, VIDC1a and IOC, the IDE/floppy connectors (lower right), the podule-backplane connector and the battery pack. Source: Chris's Acorns (Chris Whytehead collection), The Centre for Computing History. |
