File:Acorn Atom motherboard.jpg
Size of this preview: 640 × 366 pixels.
Original file (640 × 366 pixels, file size: 50 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Acorn Atom main board, part 202,000 issue 4, in its base configuration with empty sockets for the expansions. 640 × 366 pixels.
Source
[edit | edit source]
https://chrisacorns.computinghistory.org.uk/Pics/Acorn_Atom8.jpg, on the page Computers/Atom.html of Chris's Acorns (Chris Whytehead's collection, hosted by The Centre for Computing History); identical file (retrieved 2026-10-01).
Author
[edit | edit source]
Chris Whytehead.
Licence
[edit | edit source]
Chris's Acorns states that its text and photographs may be reused under CC BY-SA 3.0 unless otherwise specified, with Chris's Acorns credited as the source (Chris's Acorns home page, retrieved 2026-10-01).
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 18:02, 17 June 2026 | | 640 × 366 (50 KB) | Josh (talk | contribs) | Acorn Atom main PCB in base (unexpanded) configuration, board part no. 202,000 Issue 4, showing the empty expansion sockets. Source: Chris's Acorns (Chris Whytehead collection), hosted by The Centre for Computing History. |
