File:Acorn Electron motherboard.jpg
Summary
[edit | edit source]
Acorn Electron opened: the case top with the keyboard (upside down) at the front, and the issue 4 main board in the case base with the ULA, the pale rectangle in the middle. The power supply is at top right. 593 × 480 pixels.
Source
[edit | edit source]
https://chrisacorns.computinghistory.org.uk/Pics/Elk03.jpg, on the page Computers/Electron.html of Chris's Acorns (Chris Whytehead's collection, hosted by The Centre for Computing History); identical file (retrieved 2026-10-01).
Author
[edit | edit source]
Chris Whytehead.
Licence
[edit | edit source]
Chris's Acorns states that its text and photographs may be reused under CC BY-SA 3.0 unless otherwise specified, with Chris's Acorns credited as the source (Chris's Acorns home page, retrieved 2026-10-01).
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 18:02, 17 June 2026 | | 593 × 480 (44 KB) | Josh (talk | contribs) | Acorn Electron opened, showing the Issue 4 main PCB in the case base and the Ferranti ULA (the pale rectangle, centre). Source: Chris's Acorns (Chris Whytehead collection), hosted by The Centre for Computing History. |
