File:Acorn Risc PC 600 motherboard.jpg
Summary
[edit | edit source]
Acorn Risc PC 600 with the first case slice removed to show the main board (0197,000): the hard disc at bottom left, the on-board IDE and floppy connectors, the two CPU card sockets with RISC OS 4.39 ROMs, an i-cubed EtherLAN 600 network card, and the VRAM and memory sockets. 489 × 480 pixels.
Source
[edit | edit source]
https://chrisacorns.computinghistory.org.uk/Pics/RPC600F.jpg, on the page Computers/RiscPC600.html of Chris's Acorns (Chris Whytehead's collection, hosted by The Centre for Computing History); identical file (retrieved 2026-10-01).
Author
[edit | edit source]
Chris Whytehead.
Licence
[edit | edit source]
Chris's Acorns states that its text and photographs may be reused under CC BY-SA 3.0 unless otherwise specified, with Chris's Acorns credited as the source (Chris's Acorns home page, retrieved 2026-10-01).
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 21:30, 17 June 2026 | | 489 × 480 (50 KB) | Josh (talk | contribs) | Acorn Risc PC 600 motherboard (board 0197,000): the two CPU-card sockets and RISC OS ROMs (left), IOMD, VIDC20, VRAM and DRAM SIMM sockets, on-board IDE/floppy connectors and the backplane socket. Source: Chris's Acorns (Chris Whytehead collection), The Centre for Computing History. |
