Howard W. Sams' GridTrace photograph of the main board of the Amiga 500 power supply it examined, from Computerfacts CSCS26 (1988), printed page 34, with the grid index listing the location of each part (BD1, the capacitors, D1-D12, F1, F2, IC1-IC3, L1, L2, the MOV, Q1-Q3, the resistors, T1 and TH1).
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Rendered from File:Sams Computerfacts CSCS26 Commodore Amiga A500.pdf, PDF page 38 (printed page 34), at 200 dpi.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Howard W. Sams & Co.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Howard W. Sams & Co. (1988). Reproduced from the hosted Computerfacts folder for preservation and repair reference, with the source cited.
