Close-up of an Amiga 600 Rev. 2D main board showing U15, the quad op-amp of the audio stages, with R322 above it, C304 (22 µF) beside it, and the filter JFETs Q321 and Q331 below.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Wikimedia Commons, File:Amiga 600 Motherboard.jpg (retrieved 2026-10-25), full-resolution original 4513 × 3103.
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Ajne01 (Wikimedia Commons user).
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
CC BY-SA 4.0, as stated on the Commons file page. This crop is released under the same licence.
