File:Amstrad PC-ECD main PCB layout.png
Size of this preview: 800 × 551 pixels. Other resolution: 2,200 × 1,514 pixels.
Original file (2,200 × 1,514 pixels, file size: 780 KB, MIME type: image/png)
Summary
[edit | edit source]
The main printed circuit board of the PC-ECD enhanced colour display, which also holds the PC1640's power supply, as drawn on page 49 of Amstrad's PC1640 service manual (two scan pages joined).
Source
[edit | edit source]
Rendered from PDF pages 69–70 (printed page 49) of the hosted File:Amstrad PC1640 Service Manual.pdf.
Author
[edit | edit source]
Amstrad plc.
Licence
[edit | edit source]
Copyright Amstrad plc. Hosted for preservation and repair reference, with the source cited.
