Summary
[edit | edit source]
Component side of an Apple Macintosh II Video Card (FCC ID BCG9GRM0201, 630-0153) with the TFB controller (marked L1A3009, 344-0001-1, © Apple 87, with the Motorola logo) in a large square package at U4B, the Brooktree Bt453KP CLUT/DAC, the two oscillators, NEC video RAM and a 2732 EPROM. Downscaled from the Wikimedia Commons original to 2200 pixels wide.
Source
[edit | edit source]
Wikimedia Commons, File:Apple-macintosh-ii-video-card.jpg, originally from wiki.techtangents.net (retrieved 2026-10-04).
Author
[edit | edit source]
Akbkuku
Licence
[edit | edit source]
Creative Commons Attribution 4.0, as stated on Wikimedia Commons.
