Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
Apple's drawing of the Apple Macintosh Express Fax/Modem communications slot card, with its RJ-11 port, from page 5 of the installation guide (030-5806-A, 1994). Cropped from a 300 dpi render of the page.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:Apple Macintosh Express Fax-Modem Installation Guide (1994).pdf, from archive.org item manuallib-id-2625660 (retrieved 2026-10-02).
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Apple Computer, Inc.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Apple Computer, Inc. Manufacturer drawing used to identify the product.
