File:Apple video input card 661-0159 (Apple Module Identification).png
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
Apple's service photograph of the video input (video-in) card for the Macintosh LC 630, Quadra 630/635 and Performa 630/635 series, service part 661-0159, the card supplied in the Apple Video System and Apple TV/Video System. The S-video and RCA connectors are at the left; the large IC is marked Philips. Apple's note on the page: when 661-0159 is returned, Apple ships 661-1073.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Apple Service Source 2.0 CD-ROM set (1996), Main CD, Module Identification (PDF dated 9 February 1996), section Interface Cards, page 53; disc image in archive.org item apple-service-source-2.0-cd-rom-set-1996 (retrieved 2026-10-04). Photograph extracted from the PDF at its embedded size (321 × 237 pixels).
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Apple Computer, Inc.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Apple Computer, Inc. Hosted for preservation and repair reference, with the source cited.
