Crop of the rear edge of an Atari 2600 four-switch (CX2600A) motherboard, Rev 16: the 3.5 mm power jack J201 with the axial capacitor C242 beside it and the rear slide switch S206.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Wikimedia Commons, File:Atari-2600-Four-Switch-Motherboard-Flat.jpg (retrieved 2026-10-25).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Evan-Amos
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Public domain (released into the public domain by the author on Wikimedia Commons).
