File:Atari 2600 CX2600A regulator A203 area (Rev 16).jpg
Size of this preview: 788 × 600 pixels. Other resolution: 1,800 × 1,370 pixels.
Original file (1,800 × 1,370 pixels, file size: 551 KB, MIME type: image/jpeg)
Summary
[edit | edit source].jpg&veaction=edit§ion=1){kind=link}
.jpg&action=edit§ion=1){kind=link}
Crop of the lower left corner of an Atari 2600 four-switch (CX2600A) motherboard, Rev 16: the 78M05 regulator at A203 screwed to its tinned heatsink pad, the large axial electrolytic above it, the green film capacitor beside it, diodes CR200 and CR201 and the colour potentiometer R213.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Wikimedia Commons, File:Atari-2600-Four-Switch-Motherboard-Flat.jpg (retrieved 2026-10-25).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Evan-Amos
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Public domain (released into the public domain by the author on Wikimedia Commons).
