File:Atari 2600 Jr motherboard power jack J2.jpg
Size of this preview: 800 × 505 pixels. Other resolution: 1,300 × 820 pixels.
Original file (1,300 × 820 pixels, file size: 184 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Crop of an NTSC Atari 2600 Jr. motherboard showing the power input jack J2 at the rear edge of the board, with C1, C2 and C3 beside it and the difficulty switch S3 at the right.
Source
[edit | edit source]
Cropped at full resolution from File:Atari-2600-Jr-Motherboard-Flat.jpg, which is byte-identical to the Wikimedia Commons file File:Atari-2600-Jr-Motherboard-Flat.jpg.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released by the author on Wikimedia Commons).
