File:Atari 2600 four-switch motherboard (Rev 16).jpg
Size of this preview: 800 × 479 pixels. Other resolution: 2,200 × 1,316 pixels.
Original file (2,200 × 1,316 pixels, file size: 837 KB, MIME type: image/jpeg)
Summary
[edit | edit source].jpg&veaction=edit§ion=1){kind=link}
.jpg&action=edit§ion=1){kind=link}
Top side of an Atari 2600 four-switch (CX2600A) motherboard, etched REV 16 and C015515 (c) 1980, with the 78M05 regulator at A203, the TIA, 6507 and 6532, and the RF modulator at the lower right.
