File:Atari 2600 four-switch motherboard with shield top removed.jpg
Size of this preview: 800 × 543 pixels. Other resolution: 2,000 × 1,357 pixels.
Original file (2,000 × 1,357 pixels, file size: 546 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
An Atari 2600 four-switch (CX2600A) motherboard photographed at an angle with the top of the RF shield removed: the cartridge connector, the 6532 (C010750-03), the 6507 (C010745-03) and the TIA (C010444D-03), the red adjustable sound coil beside the 6532, the crystal at left and the RF modulator at lower right.
Source
[edit | edit source]
Cropped from Wikimedia Commons, File:Atari-2600-Four-Switch-Motherboard-02.jpg (retrieved 2026-10-25).
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released into the public domain by the author on Wikimedia Commons).
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 10:53, 25 October 2026 | | 2,000 × 1,357 (546 KB) | Josh (talk | contribs) | Upload for repair guide |
You cannot overwrite this file.
File usage
The following 3 pages use this file:
