File:Atari 2600 six-switch motherboard colour delay control R211.jpg
Size of this preview: 800 × 576 pixels. Other resolution: 1,400 × 1,008 pixels.
Original file (1,400 × 1,008 pixels, file size: 353 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Crop of the left end of a six-switch Atari 2600 (CX2600) motherboard: the colour delay potentiometer R211 (marked CLR DLY ADJ), the 3.579575 MHz crystal X200, transistors Q200 and Q201, diodes CR200 and CR201 and capacitors C208 and C209.
