File:Atari 2600 six-switch motherboard controller ports and J201.jpg
Size of this preview: 270 × 599 pixels. Other resolution: 721 × 1,600 pixels.
Original file (721 × 1,600 pixels, file size: 239 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Crop of the right-hand end of a six-switch Atari 2600 (CX2600) motherboard: the controller ports J202 and J203, the disc capacitors beside them (C229 to C237), the 12-way cable at J201 and the power jack between the ports.
Source
[edit | edit source]
Cropped from Wikimedia Commons, File:Atari-2600-Six-Switch-Motherboard-Flat.jpg (retrieved 2026-10-25).
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released into the public domain by the author on Wikimedia Commons).
