Crop of a six-switch Atari 2600 (CX2600) motherboard showing the sound oscillator parts: the two glass-cased 820 pF polystyrene capacitors C206 and C207 (marked 821J), the pink adjustable sound coil L201 with SOUND ADJ printed beside it, transistor Q202 and the 4050 at A203 below.
Source
[edit | edit source]
Cropped from Wikimedia Commons, File:Atari-2600-Six-Switch-Motherboard-Flat.jpg (retrieved 2026-10-25).
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released into the public domain by the author on Wikimedia Commons).
