File:Atari 2600 six-switch switchboard.jpg
Size of this preview: 800 × 425 pixels. Other resolution: 1,920 × 1,019 pixels.
Original file (1,920 × 1,019 pixels, file size: 223 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
The switchboard of a six-switch Atari 2600 (CX2600), removed from the console: the six slide switches with their foam dust covers, the axial 2200 uF reservoir, the regulator on its tinned heatsink area at the left, the 12-pin connector to the motherboard in the middle and the RF modulator at the right.
Source
[edit | edit source]
Wikimedia Commons, File:Atari-2600-Six-Switch-Console-07.jpg (retrieved 2026-10-25). Downscaled for this wiki.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released into the public domain by the author on Wikimedia Commons).
