File:Atari 800XL audio amplifier U1 and audio inputs (Sams CC11).png
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
Detail of the main schematic in Sams Computerfacts CC11, Atari Model 800XL (July 1985), pages 27-29: the two halves of the LM358P audio amplifier U1 with R1-R11, C17, C20, C21 and C24; the key-click feed from GTIA pin 15 through C23 and R5; the SIO audio input from J1 pin 11 through C19 (with C110); the expansion audio input through C22; and the output from U1 pin 1 through R8 (with R10 to ground) to J2 pin 3. Sams' DC readings (1.7 V at the op-amp pins, 4.3 V supply) are printed on the drawing.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Cropped from File:Sams Computerfacts Atari 800XL (CC11).pdf, PDF page 25, at the scan's 200 dpi.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Howard W. Sams & Co.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Howard W. Sams & Co., 1985. Not freely licensed. Hosted for preservation and repair reference, with the source cited.
