File:Atari Jaguar motherboard, REG1 audio regulator and TP6.jpg
Size of this preview: 660 × 430 pixels.
Original file (660 × 430 pixels, file size: 108 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Crop of an Atari Jaguar main board (assembly 700026, label 700026-001) showing the eight-pin audio regulator REG1 with R63 below it, the test point TP6 to its right and two electrolytic capacitors beside it. The TDA1308 amplifier U4 is at the bottom of the crop.
Source
[edit | edit source]
Cropped at full resolution from the Wikimedia Commons file File:Atari-Jaguar-Motherboard-Flat.jpg.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released by the author on Wikimedia Commons).
