Schematic of the Mitsumi SR98 switching power supply used in long-case Atari ST computers: Atari Corporation drawing C103594, "Power Supply 27 W 220 V Sweden", sheet 7 of 8, revision A (1987). It shows the mains input with the 250 V T1A fuse, line filter L101, bridge D101, inrush resistor R101 and reservoir C104; the switching transistor Q101 (2SC2979) and its drive circuit; the +5 V and +12 V output rectifiers and filters; the TL431-type reference IC201 with the divider R201, R202 and the 5 V adjustment VR201; and the six-way output connector CH2 with its wire colours. Rendered from page 8 of File:Atari SR98 Power Supply Specification C103594.pdf and turned to landscape.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:Atari SR98 Power Supply Specification C103594.pdf, page 8 (retrieved 2026-10-25 from exxos's compilation at https://www.exxosforum.co.uk/atari/last/psu/index.htm).
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Atari Corporation.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Atari Corporation. Hosted for preservation and repair reference, with the source cited.
