The XE keyboard matrix from JER/Eightbitter's reconstruction of the 130XE field service manual (figure 2-15), rotated so that the key names read across. Each key sits where a row line and a column line cross, and the numbers on the lines are the pins of the keyboard connector J8. START, SELECT, OPTION and RESET are on line 3 with lines 21 to 24, and the power LED D1 is between lines 2 and 3.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Rendered at 300 dpi with pdftoppm from page 34 of File:Atari 130XE Field Service Manual.pdf, hosted on this wiki, cropped and rotated 90 degrees.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
JER/Eightbitter (redrawing)
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Not stated at the source. Hosted for repair reference, with the source cited.
