Summary

The inside of a 10.8 V 4.8 Ah laptop battery: six Panasonic CGR18650DA cells wired as two parallel strings of three in series, with the protection board below and a match for scale. Used on Battery Refurbishment.

Source

Wikimedia Commons, File:Lithiumion-laptop-battery-internals.jpg

Author

Lead holder

Licence

CC BY-SA 3.0
