File:Battery guide - spot weld nugget cross section.png
Size of this preview: 800 × 517 pixels. Other resolution: 1,257 × 813 pixels.
Original file (1,257 × 813 pixels, file size: 17 KB, MIME type: image/png)
Summary
[edit | edit source]
Cross-sections of resistance spot welds, showing the fused nugget (diameter d) between two sheets and the electrode indentations, from the Soviet standard GOST 15878-79. Used on Battery Refurbishment.
Source
[edit | edit source]
Wikimedia Commons, File:Structural schematic section of Spot Weld.png
Author
[edit | edit source]
GOST 15878-79, as credited on Commons
Licence
[edit | edit source]
Public domain (as a Soviet state standard, according to Commons)
