File:Charred step-down regulator on a laptop board (microscope).jpg
Size of this preview: 800 × 600 pixels. Other resolution: 2,000 × 1,500 pixels.
Original file (2,000 × 1,500 pixels, file size: 646 KB, MIME type: image/jpeg)
Summary
[edit | edit source].jpg&veaction=edit§ion=1){kind=link}
.jpg&action=edit§ion=1){kind=link}
Microscope photograph of a failed SY8386BRHC step-down converter IC on a green multilayer laptop circuit board. The IC package is charred and split, the laminate beside it is blackened, and copper is exposed where the surface has burnt away; surface-mount capacitors, resistors and an inductor surround it.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Wikimedia Commons, File:Microscope close-up of blown step-down regulator on laptop PCB.jpg (retrieved 2026-10-25). Downscaled from 4032 x 3024 pixels.
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Profpcde (Wikimedia Commons user), 2023.
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
CC0 1.0 Public Domain Dedication, as recorded on Wikimedia Commons.
