Crop at full resolution from Evan-Amos's photograph of a ColecoVision logic board (75743 Rev H2-1), showing the two 10 µF radial electrolytics C34 and C36 beside the RF shield, the inductors next to them, the SN76489AN sound chip (U20), wire jumpers WJ2 and WJ3 and the 10 µF electrolytic C16. C36 is marked 16 V.
Source
[edit | edit source]
Cropped from Wikimedia Commons, File:ColecoVision-Motherboard-Top.jpg (retrieved 2026-10-19).
Author
[edit | edit source]
Evan-Amos (photograph); cropped for this wiki.
Licence
[edit | edit source]
Public domain: released by the author (PD-self on Wikimedia Commons).
