The board of a CBS Electronics version of the Expansion Module #1 (the "Atari Converter"), described by ColecoVision.dk as an older Rev. A board. U3 is marked "8339-VA-1292 (0004) VF4023-0001 13717 USA-I", U1 is a Rockwell R6507P (R6507-11) and U2 a Rockwell R6532P (R6532-32). A transistor oscillator with two crystals sits at the left, the trimmer R38 at the top, one small blue electrolytic beside L1 and C31 at the top left, slide switches S1-S3 and push buttons S4 and S5 along the front, and the controller sockets J3 and J4 at the lower right.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
ColecoVision.dk, "CBS Atari Converter inside", image file images/atari cbs converter inside-big.jpg, linked from "ColecoVision Technical" (retrieved 2026-10-19).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
ColecoVision.dk (Ole Nielsen).
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Copyright ColecoVision.dk. No free licence is stated. Used with credit for identification and repair reference.
