File:ColecoVision Expansion Module 2 board 55888 Rev D, solder side (ColecoVision.dk).jpg
Size of this preview: 800 × 373 pixels. Other resolution: 1,000 × 466 pixels.
Original file (1,000 × 466 pixels, file size: 203 KB, MIME type: image/jpeg)
Summary
[edit | edit source].jpg&veaction=edit§ion=1){kind=link}
.jpg&action=edit§ion=1){kind=link}
The solder side of the Expansion Module #2 steering wheel board, marked "55888 REV D", "COLECO" and "1982", with Q1, Q2, Q3 and U1 identified in the silkscreen. Green and brown corrosion surrounds a group of pads in the middle of the board. The red and white wires at the lower left are the supply leads.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
ColecoVision.dk, "ColecoVision Technical", image file images/steering-wheel-close.jpg (retrieved 2026-10-19).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
ColecoVision.dk (Ole Nielsen).
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Copyright ColecoVision.dk. No free licence is stated. Used with credit for identification and repair reference.
