File:Commodore 64C 250469 board U9 SID 8580 and SID supply.jpg
Size of this preview: 602 × 345 pixels.
Original file (602 × 345 pixels, file size: 106 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Detail of a Commodore 64C main board, assembly 250469 (C64E Rev. B, 1992), showing the SID at U9 (a CSG 8580R5), the CIA at U2 (CSG 6526A), the 4066 at U18, the capacitor positions C70, C79, C80, C81 and C39, the R8 and R9 positions, and the SID supply parts Q5, CR3, CR4, CR7, R100 and C66, with CR2 at the top right.
Source
[edit | edit source]
Cropped from Wikimedia Commons, File:C64Cmotherboard.jpg (retrieved 2026-10-25).
Author
[edit | edit source]
Bill Bertram, via Wikimedia Commons
Licence
[edit | edit source]
CC BY-SA 3.0. This crop is released under the same licence.
