File:Commodore 64 250407 board U18 SID 6581.jpg
Size of this preview: 576 × 456 pixels.
Original file (576 × 456 pixels, file size: 112 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Detail of a Commodore 64 main board, assembly 250407 Rev. B, showing the SID at U18 (a MOS 6581), with the 2114 colour RAM (MSM2114L) at U6 and the capacitor position C10 above it.
Source
[edit | edit source]
Cropped from Wikimedia Commons, File:0430 - C64 Mainboard ASSY250407 RevB.jpg (retrieved 2026-10-25).
Author
[edit | edit source]
Sven.petersen, via Wikimedia Commons
Licence
[edit | edit source]
CC BY-SA 4.0. This crop is released under the same licence.
