Summary
[edit | edit source]
Detail of a Commodore 64 main board, assembly 250425 (PAL, 1984), showing the PLA at U17, a MOS 906114-01, with U15 (74LS139), U27 (74LS08) and U14 to its left.
Source
[edit | edit source]
Cropped from Wikimedia Commons, File:C64 ASSY NO 250425 motherboard 1984.jpg (retrieved 2026-10-25).
Author
[edit | edit source]
Gona.eu, via Wikimedia Commons
Licence
[edit | edit source]
CC BY-SA 3.0. This crop is released under the same licence.
