File:Creative 3DO Blaster CT6110 audio and video section.jpg
Summary
[edit | edit source]
The bracket end of a Creative 3DO Blaster card (CT6110), photographed at an angle: the cluster of small radial electrolytic capacitors beside the two CD audio connectors, the Brooktree Bt121 (U65), the electrolytics C36, C40 and C45 below the feature connector header, C126 beside the CD audio connector, the blue electrolytic C180 below the Bt121, the BLK_SEL jumper, and the D-sub sockets on the bracket.
Source
[edit | edit source]
Cropped from photograph dsc04998.jpg on archive3do.com, Creative Blaster page, https://archive3do.com/creative-blaster/ (retrieved 2026-10-21).
Author
[edit | edit source]
Not separately credited; the source page credits its photographs to Bitrate (AtariAge).
Licence
[edit | edit source]
Copyright the photographer. Hosted for repair reference, with the source cited.
