File:DIP sockets.jpg
Size of this preview: 594 × 599 pixels. Other resolution: 706 × 712 pixels.
Original file (706 × 712 pixels, file size: 79 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Three stamped-contact DIP sockets for 16-, 14- and 8-pin packages, with a tape measure marked in centimetres for scale. Copied from Wikimedia Commons.
Source
[edit | edit source]
Wikimedia Commons, File:DIP sockets.jpg (retrieved 2026-10-25).
Author
[edit | edit source]
Omegatron (Wikimedia Commons user)
Licence
[edit | edit source]
CC BY-SA 3.0, as stated on Wikimedia Commons.
