File:Desoldering with hot air.jpg
Size of this preview: 800 × 532 pixels. Other resolution: 2,200 × 1,464 pixels.
Original file (2,200 × 1,464 pixels, file size: 933 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
A hot-air rework nozzle surrounding a large quad flat pack (QFP) on a circuit board, with a vacuum pick-up cup resting on the top of the package. Copied from Wikimedia Commons, where the photographer describes it as desoldering an IC with hot air.
Source
[edit | edit source]
Wikimedia Commons, File:Desoldering with hot air.jpg (retrieved 2026-10-25). Downscaled from 4064 x 2704 pixels.
Author
[edit | edit source]
Aisart (Wikimedia Commons user)
Licence
[edit | edit source]
CC BY-SA 3.0 (also GFDL), as stated on Wikimedia Commons.
