An Elenco LP-560 logic probe held in the hand: HI and LO lamps near the tip, a TTL/CMOS switch, a PULSE/MEM switch and a lamp between them, and the coiled lead ending in red and black clips for the circuit's supply. Used on Continuity Testing and Signal Tracing.
Source
[edit | edit source]
Wikimedia Commons, File:Elenco Logic probe LP-560.jpg (retrieved 2026-10-25), originally published on Flickr as "Logic probe". Downscaled to 1920 px wide.
Author
[edit | edit source]
Plusea.
Licence
[edit | edit source]
Creative Commons Attribution 2.0 Generic (CC BY 2.0), https://creativecommons.org/licenses/by/2.0/
