Three 5 × 20 mm cartridge fuses side by side: on the left a glass tube with its thin wire element visible, in the middle a glass tube filled with sand, and on the right a sand-filled ceramic tube whose end cap is stamped H 250V. Used as the lead image of Fuse Identification and Replacement.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Wikimedia Commons, File:Different Types of 5x20 Fuses.jpg (retrieved 2026-10-25). Downscaled to 1920 px.
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Medvedev.
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Creative Commons Attribution-ShareAlike 3.0 Unported (CC BY-SA 3.0), https://creativecommons.org/licenses/by-sa/3.0/
