File:IBM PC 300PL 6892 motherboard.jpg
Size of this preview: 800 × 600 pixels. Other resolution: 1,280 × 960 pixels.
Original file (1,280 × 960 pixels, file size: 259 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
System board of an IBM PC 300PL, type 6892-5BJ, in the opened case: a Slot 1 Intel processor cartridge under its heatsink, three DIMM sockets and the expansion slots.
Source
[edit | edit source]
https://commons.wikimedia.org/wiki/File:Ibm_6892-5bj_pcb.jpg (retrieved 2026-10-01). Originally published on https://www.okqubit.net/machines/ibm.html
Author
[edit | edit source]
okqubit.net.
Licence
[edit | edit source]
Public domain: the okqubit.net page where it was first published places all of its images in the public domain, free for any personal or commercial use.
