File:MCM4116B 4116 dynamic RAM chip.jpg
Size of this preview: 800 × 533 pixels. Other resolution: 1,200 × 800 pixels.
Original file (1,200 × 800 pixels, file size: 180 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
A Motorola MCM4116B, a 16,384 × 1 bit dynamic RAM of the 4116 type, in a purple ceramic package. The 4116 is the main RAM chip in the dynamic Commodore PET boards of the 4000 series.
Source
[edit | edit source]
Wikimedia Commons, File:MCM4116B DRAM IC (55610490178).jpg (retrieved 2026-10-25). Downscaled for this wiki.
.jpg){kind=link}
Author
[edit | edit source]
Dave Ruske
Licence
[edit | edit source]
CC BY 4.0, as stated on the Commons file page.
