File:Mac IIvi Recap Guide.jpg
Size of this preview: 709 × 599 pixels. Other resolution: 2,048 × 1,731 pixels.
Original file (2,048 × 1,731 pixels, file size: 1.26 MB, MIME type: image/jpeg)
Summary
[edit | edit source]
Recap-a-Mac's annotated photograph of the Macintosh IIvi logic board, with each electrolytic capacitor marked with its value and voltage. The legend lists 6 × 47 µF 16 V and 2 × 220 µF 16 V. It is also used on the Macintosh IIvx pages.
Source
[edit | edit source]
Recap-a-Mac, https://recapamac.com.au/wp-content/uploads/2019/08/mac_iivi_recap.jpg, linked from https://recapamac.com.au/macintosh-iivi/ (retrieved 2026-10-01). Identical to this file (same SHA-1).
Author
[edit | edit source]
Recap-a-Mac (recapamac.com.au), Branchus Creations.
Licence
[edit | edit source]
Copyright Recap-a-Mac. No licence is stated on the source site; reproduced here as a repair reference with the source cited.
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 12:32, 9 February 2026 | | 2,048 × 1,731 (1.26 MB) | Josh (talk | contribs) | Macintosh IIvi/IIvx logic board capacitor replacement guide. Source: Recap-a-Mac |
