File:MacintoshPlus LogicBoard Shematic.jpg
Size of this preview: 776 × 600 pixels. Other resolutions: 2,560 × 1,978 pixels | 13,200 × 10,200 pixels.
Original file (13,200 × 10,200 pixels, file size: 15.61 MB, MIME type: image/jpeg)
Summary
[edit | edit source]
Apple drawing 050-0159-A, Schematic, Mac+ Main Logic PCB, sheet 1 of 1, released March 1986: the Macintosh Plus logic board. 13,200 × 10,200 pixels. The file name misspells "Schematic". Used on Macintosh Plus.
Source
[edit | edit source]
Source not recorded.
Author
[edit | edit source]
Apple Computer, Inc.
Licence
[edit | edit source]
Copyright Apple Computer, Inc.; the sheet carries Apple's notice of proprietary property. Not freely licensed. Hosted for repair reference.
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 11:01, 12 March 2025 | | 13,200 × 10,200 (15.61 MB) | Josh (talk | contribs) | Macintosh Plus Logic Board Schematic |
You cannot overwrite this file.
File usage
The following page uses this file:
