File:Mattel Aquarius power supply section.jpg
Size of this preview: 800 × 514 pixels. Other resolution: 1,195 × 768 pixels.
Original file (1,195 × 768 pixels, file size: 200 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Detail of the Mattel Aquarius main board: the 10,000 µF axial smoothing capacitor, a Shoei 25 V radial capacitor, the incoming power lead and its connector, the TO-220 regulator with its mounting screw, and a small 85 °C electrolytic beside two transistors. Cropped from the Commons photograph of the board.
Source
[edit | edit source]
Wikimedia Commons, File:Mattel-Aquarius-Motherboard-FL.jpg (retrieved 2026-10-19). Cropped from the original.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released into the public domain by the author)
