File:Membrane trace repair diagram.png
Summary
[edit | edit source]
Two-part diagram of a membrane keyboard trace repair. Top: plan view of a printed silver trace under its lacquer with a crack across it, the small scraped test spots used to narrow down the break, and the window of about 20 mm of trace exposed round the crack. Bottom: cross-section of the finished repair, with conductive silver ink bridging the gap, two or three single strands of 30 AWG wire laid in the ink, and a thin layer of resin over the ink and wires. Not to scale.
Source
[edit | edit source]
Drawn for this wiki in October 2026 from the repair described in "Amiga 500 Samsung Keyboard Repair", hackup.net, December 2024, https://www.hackup.net/2024/12/amiga-500-samsung-keyboard-repair/ (retrieved 2026-10-25), steps 3 to 7. Used on Keyboard Membrane Trace Repair.
Author
[edit | edit source]
RetroTechCollection wiki.
Licence
[edit | edit source]
Released under CC BY-SA 4.0 (https://creativecommons.org/licenses/by-sa/4.0/).
