File:MicroVAX 3100 Model 10 and Model 20 enclosures (EK-A0371-OM-002 Figure 1-1).png
Size of this preview: 800 × 554 pixels. Other resolution: 1,224 × 848 pixels.
Original file (1,224 × 848 pixels, file size: 32 KB, MIME type: image/png)
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
DEC drawing of the MicroVAX 3100 and VAXserver 3100 Model 10 and Model 20 system enclosures, Figure 1-1 of the owner's manual, rendered at 200 dpi.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:MicroVAX 3100 and VAXserver 3100 Owner's Manual (EK-A0371-OM-002).pdf, p. 1-2.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Digital Equipment Corporation.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Digital Equipment Corporation. Hosted for preservation and repair reference, with the source cited.
