File:N64 NUS-CPU-03-04 schematic audio and video output (RDC).png
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
Crop of the audio and video output section of the community-drawn Nintendo 64 NUS-CPU-03/04 mainboard schematic: VDC-NUS (U4) and ENC-NUS (U5) with the 110 Ω loads R8 to R10 and coupling capacitors C124 to C126; the composite, luma and chroma outputs through C15, C16 and C14 and the 75 Ω resistors R5, R6 and R7; the BU9480F audio DAC (U1), coupling capacitors C31 and C32, the AMP-NUS amplifier (U2) with C24, C28, C29, C30, R17 and R21; the audio outputs through C25, C26, R57 and R58; and the multi-out connector P7. Rendered at 600 dpi from the hosted PDF.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Cropped from File:N64 NUS-CPU-03-04 Schematic.pdf, described on N64 NUS-CPU-03-04 Schematic.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
RDC (drawing dated 02-07-2013). A community drawing, not a Nintendo document.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
No licence is stated on the drawing. Hosted for repair reference with the source cited.
