File:NASA-STD-8739.2 Figure B-6, gull wing lead solder fillet.png
Summary
[edit | edit source]
Figure B-6, Gull Wing Lead Solder, from Appendix B of NASA-STD-8739.2: minimum and maximum acceptable solder on a gull-wing lead. In both a concave fillet joins lead and land, a heel fillet is mandatory, and at maximum the contour of the lead remains visible through the fillet. Cropped from PDF page 72.
Source
[edit | edit source]
NASA, NASA-STD-8739.2 Workmanship Standard for Surface Mount Technology, 31 August 1999. NASA-hosted copy at https://s3vi.ndc.nasa.gov/ssri-kb/static/resources/NASA-STD-8739-2.pdf (retrieved 2026-10-25). The standard was cancelled on 17 October 2011.
Author
[edit | edit source]
NASA
Licence
[edit | edit source]
Public domain. This is a work of the United States Government (NASA), not subject to copyright in the United States.
